Feature
* Meet the requirement of international SNMP network management, support distant control or local button operation
to the receiver.
* Adopt advanced low noise, high capability and high reliable gallium arsenide chip, can improve the C/N and nonlinear
distortion and reduce the machine’s consumption which is less than 10W.
* Strict reliability test, MTBF is more than 100,000 hours.
* Digital real-time display of the operating parameter, electric modulation attenuator(A) and equalizer(E). External
power switch has passed the 3C certification.
-
ITEM
UNIT
PARAMETER
Optical Wavelength
nm
1200-1600
Optical Connecting Type
FC/APC or SC/APC
Optical Receiving Power Range
dBm
-9 - +3
Optical AGC Range
dBm
-7 - +2
Frequency Range
MHz
45-862/1000
Frequency Respond Flatness
dB
±1.0
RF Port Number
PCS
1
2
Nominal Output Power Level
dBuV
106
102
Test Port
dB
-20±2
Output RF Impedance
Ω
75
Gain Power Adjustment Range
dB
0-15
Equalizing Adjustment Range
dB
0-15
Output Return
dB
>14
Equivalent Noise Coefficient
PA√HZ
≤8
C/N
dB
>50
CTB
dBc
>61
CSO
dBc
>60
Voltage
V
External 12VDC
Operating Temperature
℃
-40 - +60
Consumption
W
<10
Dimension
mm
165*160*38
