Feature
* Adopt high quality high sensitive PIN optical detector and gallium arsenide RF amplification module to ensure low
noise, low distortion, high capability and reliability.
* Optical power level indicator light can display in the level of -5dBm, -4dBm, -3dBm, -2dBm, -1dBm,
0dBm, +1dBm, +2dBm which is convenient for technician to inspect and maintain.
* Ensure electromagnetic shielding and radiating capability of the optical receiver.
* Equalizer and attenuator are successive adjustable.
* 2 ways output, ensure superior nonlinear index.
* 60VAC independent power supply
-
ITEM
UNIT
PARAMETER
Operating Bandwidth
MHz
45-862
Optical Operating Wavelength
nm
1290-1600
Input Optical Power Range
dBm
-9 - +3
Optical AGC Range
dBm
-7 - +2
Optical Return Loss
dB
≥45
Equivalent Noise Coefficient
PA√HZ
≤8
Flatness
dB
±1.0
Return Loss
dB
≥14
RF Input Impedance
Ω
75
CNR
dB
51
CTB
dB
≥63
CSO
dB
≥58
Nominal Output Power Level
dBuV
106
Output Port Number
PCS
2
Input Voltage Range
VAC
35-90/220±10%
Operating Temperature
℃
-40 - +60
Consumption
W
<12
Dimension
(Include Head F)
mm
230*145*95
